Pipe Fittings Shipment to Australia for Multi-Standard Piping Systems

Haihao Group has successfully completed a shipment of carbon steel pipe fittings for an Australian customer, covering a wide range of threaded, socket weld, and butt weld components. The products were manufactured in accordance with ASME, MSS, and EN standards, with materials selected to meet different service conditions and installation requirements.

Product Scope and Technical Overview

The delivered pipe fittings include multiple connection types and sizes, designed for flexible integration into industrial piping systems:

Threaded and Nipple Products

• Double Ended Nipple, 100 mm, Plain End
  • Size: 0.5 inch, SCH 80
  • Standard: ASME B36.10
  • Material: ASTM A333 Grade 6
  • Surface: Rust preventive oil
• Double Ended Nipple, 100 mm
  • Size: 0.75 inch, wall thickness 3.2 mm
  • Standard: ASME B36.10
  • Material: ASTM A106 Grade B, galvanized
  • Thread: BSPT external thread

These nipples are commonly used for equipment connections and compact piping layouts where precise threading and strength are required.

Threaded Elbows and Reducing Tees

• 45 Degree Threaded Elbow
  • Size: 1.5 inch
  • Thread: BSPTF
  • Standard: EN 10241
  • Material: ASTM A105N, hot dip galvanized
• Reducing Threaded Tee
  • Size: 1.5 inch x 0.75 inch
  • Thread: BSPTF / NPTF
  • Standard: EN 10241 / ASME B16.11
  • Pressure class: 3000# (for NPT type)
  • Material: ASTM A105N, hot dip galvanized

These fittings are widely used in low- to medium-pressure service lines, offering easy installation and strong sealing performance.

Threaded and socket weld pipe fittings ASME B16.11 MSS SP-97 manufactured by Haihao Group

Socket Weld Branch and Elbows

• Socket Weld Branch Outlet
  • Size: 3 inch x 0.5 inch
  • Pressure class: 3000#
  • Standard: MSS SP-97
  • Material: ASTM A350 LF2 Class 1
  • Surface: Rust preventive oil
• 45 Degree Socket Weld Elbow
  • Size: 1.5 inch
  • Pressure class: 3000#
  • Standard: ASME B16.11
  • Material: ASTM A105N
  • Surface: Rust preventive oil

Socket weld fittings provide excellent strength and are suitable for high-pressure and low-temperature service environments.

Reducers and Lap Joint Components

• Concentric and Eccentric Reducers
  • Sizes: 1.5 inch x 0.75 inch, 2 inch x 0.75 inch, 2 inch x 1 inch
  • Standards: MSS SP-95
  • Material: ASTM A105N, galvanized or oiled
• Long Stub End (Lap Joint Type)
  • Size: 4 inch SCH 40
  • Standard: ASME B16.9
  • Material: ASTM A234 WPB
  • Surface: Black paint

Surface Treatment and Quality Assurance

To meet Australian project requirements, fittings were supplied with either hot dip galvanizing for corrosion resistance or rust preventive oil for temporary protection during storage and transportation. Each item underwent dimensional inspection and material verification prior to shipment.

Haihao Group ensures all products comply with the specified standards and customer technical drawings, supporting reliable on-site installation.

Reliable Pipe Fittings Supplier for the Australian Market

With extensive experience supplying pipe fittings to Australia, Haihao Group provides flexible manufacturing solutions covering threaded fittings, socket weld fittings, reducers, nipples, and branch outlets. Our products are widely used in construction, energy, industrial piping, and maintenance projects.

If you are looking for a dependable supplier of ASME and EN standard carbon steel pipe fittings for Australia, Haihao Group is ready to support your project with consistent quality and professional service.
